RF-HY30R
Superisys
RS485, RS232, Ethernet
| Availability: | |
|---|---|
| Quantity: | |
High-frequency (13.56MHz) precision RFID readers are special equipment developed for high-precision identification scenarios. They have irreplaceable advantages in chip-level identification, medical sterilization, precision manufacturing and other fields.
| Minimum Order Quantity | one |
| Price | receive bargaining |
| Delivery Time | 5-8 Work Days |
| Stock | In Stock |
| Description | RFID read/write head HF, external diameter M30×60mm, 13.56MHz |
| Payment Terms | T/T, Western Union |
| Supply Ability | 1000 per day |
| product model | RF-HY30R-R4 | RF-HY30R-R2 | RF-HY30RE-TP | RF-HY30R-IOL |
| wireless protocol | ISO15693 | |||
| working frequency | 13.56MHz | |||
| output power | 27.5dBm | |||
| wireless speed | 26.48Kbit/s | |||
| Read distance | 0~60mm(Related to the loaded code body) | |||
| communication interface | RS485 | RS232 | Ethernet | IO Link |
| communication protocol | MODBUS RTU | MODBUS RTU | MODBUS TCP | IO-Link V1.1 |
| Communication rate | 9600~115200bit/s | 9600~115200bit/s | 10/100M (Adaptive) | 230.4kbps |
| Input | 9~30VDC | |||
| average current | ＜0.07A@24VDC | |||
| indicator light | 1 LED indicator | |||
| boundary dimension | M30×61mm | M30×61mm | M30×72mm | M30×72mm |
| Product interface | M12 Acode 4PIN male head | M12 Acode 4PIN male head | M12 Acode 8PIN male head | M12 Acode 8PIN male head |
| Installation | Nut fixed, screw tooth M30*1.5 | |||
| Material | Brass plated with nickel +ABS | |||
| Shell color | Silver + Black | |||
| total weight | 65g | 65g | 70g | 70g |
| operating temperature | ~25℃~+70℃ | |||
| storage temperature | ~40℃~+85℃ | |||
| humidity | 5%~95%RH(without condensation) | |||
| Waterproof and dustproof grade | IP67,EN 60529 | |||
| Resistance to vibration | 2 mm (f= 5…29.5 Hz ) , EN 60068-2-6 7 gn (f= 29.5…150 Hz) , EN 60068-2-6 | |||
| Conduction immunity (CS) | 3V, Class A (including main frequency) 10V, Class A (except main frequency) | |||
| Electrostatic discharge immunity ESD | Contact discharge, 8KV, Class A air discharge, 15KV, class A IEC61000-4-2 | |||
| Certificate | FCC CE | |||
| ROHS instruct | 2011/65/EU,2015/863/EU | |||
High-frequency (13.56MHz) precision RFID readers are special equipment developed for high-precision identification scenarios. They have irreplaceable advantages in chip-level identification, medical sterilization, precision manufacturing and other fields.
| Minimum Order Quantity | one |
| Price | receive bargaining |
| Delivery Time | 5-8 Work Days |
| Stock | In Stock |
| Description | RFID read/write head HF, external diameter M30×60mm, 13.56MHz |
| Payment Terms | T/T, Western Union |
| Supply Ability | 1000 per day |
| product model | RF-HY30R-R4 | RF-HY30R-R2 | RF-HY30RE-TP | RF-HY30R-IOL |
| wireless protocol | ISO15693 | |||
| working frequency | 13.56MHz | |||
| output power | 27.5dBm | |||
| wireless speed | 26.48Kbit/s | |||
| Read distance | 0~60mm(Related to the loaded code body) | |||
| communication interface | RS485 | RS232 | Ethernet | IO Link |
| communication protocol | MODBUS RTU | MODBUS RTU | MODBUS TCP | IO-Link V1.1 |
| Communication rate | 9600~115200bit/s | 9600~115200bit/s | 10/100M (Adaptive) | 230.4kbps |
| Input | 9~30VDC | |||
| average current | ＜0.07A@24VDC | |||
| indicator light | 1 LED indicator | |||
| boundary dimension | M30×61mm | M30×61mm | M30×72mm | M30×72mm |
| Product interface | M12 Acode 4PIN male head | M12 Acode 4PIN male head | M12 Acode 8PIN male head | M12 Acode 8PIN male head |
| Installation | Nut fixed, screw tooth M30*1.5 | |||
| Material | Brass plated with nickel +ABS | |||
| Shell color | Silver + Black | |||
| total weight | 65g | 65g | 70g | 70g |
| operating temperature | ~25℃~+70℃ | |||
| storage temperature | ~40℃~+85℃ | |||
| humidity | 5%~95%RH(without condensation) | |||
| Waterproof and dustproof grade | IP67,EN 60529 | |||
| Resistance to vibration | 2 mm (f= 5…29.5 Hz ) , EN 60068-2-6 7 gn (f= 29.5…150 Hz) , EN 60068-2-6 | |||
| Conduction immunity (CS) | 3V, Class A (including main frequency) 10V, Class A (except main frequency) | |||
| Electrostatic discharge immunity ESD | Contact discharge, 8KV, Class A air discharge, 15KV, class A IEC61000-4-2 | |||
| Certificate | FCC CE | |||
| ROHS instruct | 2011/65/EU,2015/863/EU | |||
1. Identification accuracy control
Reading distance can be precisely controlled within 0.1-5cm (adjustable)
Using near-field coupling technology, positioning accuracy reaches ±0.5mm
Support single-tag operation mode to avoid interference from adjacent tags
2. Communication reliability
Comply with ISO/IEC 15693, ISO14443A/B protocols
Bit error rate <0.001% (under 50dB signal-to-noise ratio environment)
Anti-metal interference ability is 60% higher than that of ordinary HF readers
3. Environmental adaptability
Working temperature -30℃~70℃
Protection level IP67 (some medical models can reach IP69K)
Electromagnetic compatibility is certified by IEC 61000-4-3 Level 4
1. Chip packaging Wafer tray identification 0.1mm level positioning to prevent chip mixing
2. Medical sterilization Surgical instrument basket tracking Resistant to 132℃ steam sterilization cycle
3. Precision manufacturing Micro bearing component management Identification of micro tags below φ3mm
4. Smart warehousing Precious metal warehouse management Millimeter-level spacing multi-tag distinction
5. Anti-counterfeiting traceability Luxury chip authentication Encrypted communication + physical unclonable function (PUF)
6. Scientific research experiments Biological sample tube management Low temperature environment identification without metal interference.
1. Identification accuracy control
Reading distance can be precisely controlled within 0.1-5cm (adjustable)
Using near-field coupling technology, positioning accuracy reaches ±0.5mm
Support single-tag operation mode to avoid interference from adjacent tags
2. Communication reliability
Comply with ISO/IEC 15693, ISO14443A/B protocols
Bit error rate <0.001% (under 50dB signal-to-noise ratio environment)
Anti-metal interference ability is 60% higher than that of ordinary HF readers
3. Environmental adaptability
Working temperature -30℃~70℃
Protection level IP67 (some medical models can reach IP69K)
Electromagnetic compatibility is certified by IEC 61000-4-3 Level 4
1. Chip packaging Wafer tray identification 0.1mm level positioning to prevent chip mixing
2. Medical sterilization Surgical instrument basket tracking Resistant to 132℃ steam sterilization cycle
3. Precision manufacturing Micro bearing component management Identification of micro tags below φ3mm
4. Smart warehousing Precious metal warehouse management Millimeter-level spacing multi-tag distinction
5. Anti-counterfeiting traceability Luxury chip authentication Encrypted communication + physical unclonable function (PUF)
6. Scientific research experiments Biological sample tube management Low temperature environment identification without metal interference.
