RF-HZMTY300-112/2K
Superisys
Non Anti-Metal Tag
Availability: | |
---|---|
Quantity: | |
High-frequency anti-metal tags have shown extensive application potential in the Industry 4.0 environment, and their contribution to improving production efficiency, asset management and data integration cannot be underestimated.
Minimum Order Quantity | one |
Price | A large amount is negotiable |
Delivery Time | 5-8 Work Days |
Stock | In Stock |
Payment Terms | T/T, Western Union |
Supply Ability | 1000 per day |
product model | RF-HZMTY300-112 | RF-HZMTY300-2K |
working frequency | 13.56MHz | |
Air port agreement | ISO 15693 | |
Read distance | 0-90mm(Related to read head) | |
User memory | 112 Bytes | 2000 Bytes |
Memory type | EEPROM | FRAM |
Rewrite cycle | 100,000 times | 10 Billion times |
Data storage time | 10 years | 10 years |
size | φ30*4mm | |
Housing material | PPS | |
Fixed mode | Scewing | |
IP rating | IP67 | |
Operating temperature | -40~70℃ | |
Storage temperature | -40~+105℃ | |
Metal resistance | Non-Antimetal metal |
High-frequency anti-metal tags have shown extensive application potential in the Industry 4.0 environment, and their contribution to improving production efficiency, asset management and data integration cannot be underestimated.
Minimum Order Quantity | one |
Price | A large amount is negotiable |
Delivery Time | 5-8 Work Days |
Stock | In Stock |
Payment Terms | T/T, Western Union |
Supply Ability | 1000 per day |
product model | RF-HZMTY300-112 | RF-HZMTY300-2K |
working frequency | 13.56MHz | |
Air port agreement | ISO 15693 | |
Read distance | 0-90mm(Related to read head) | |
User memory | 112 Bytes | 2000 Bytes |
Memory type | EEPROM | FRAM |
Rewrite cycle | 100,000 times | 10 Billion times |
Data storage time | 10 years | 10 years |
size | φ30*4mm | |
Housing material | PPS | |
Fixed mode | Scewing | |
IP rating | IP67 | |
Operating temperature | -40~70℃ | |
Storage temperature | -40~+105℃ | |
Metal resistance | Non-Antimetal metal |
1. Protection level: IP67/IP68 (dustproof and waterproof), suitable for harsh industrial environments
2. Anti-metal design: PPS material is used to offset metal interference and ensure signal stability.
3. Temperature range: usually -25°C to +85°C (some models can reach 125°C)
1. Protection level: IP67/IP68 (dustproof and waterproof), suitable for harsh industrial environments
2. Anti-metal design: PPS material is used to offset metal interference and ensure signal stability.
3. Temperature range: usually -25°C to +85°C (some models can reach 125°C)
FAQ
Q1: Does the HF RFID Tag require an external antenna on the metal surface?
A: No external antenna is required. HZMTY300 has a built-in anti-metal substrate and can be directly attached to the metal surface for use.
Q2: How is the high temperature resistance of the tag?
A: The operating temperature range is -40℃~105℃, suitable for high-temperature sterilization (such as medical equipment) or low-temperature storage scenarios.
Q3: Does it support batch encoding?
A: Yes. UID or user data can be quickly written in batches through the reader/writer to improve deployment efficiency.
Q4: How long is the life of the tag?
A: Passive design, theoretical life of more than 10 years, read and write times ≥100,000 times, no daily maintenance requirements.
Q5: How to ensure data security?
A: Supports password protection and data encryption to prevent unauthorized tampering or cloning.
FAQ
Q1: Does the HF RFID Tag require an external antenna on the metal surface?
A: No external antenna is required. HZMTY300 has a built-in anti-metal substrate and can be directly attached to the metal surface for use.
Q2: How is the high temperature resistance of the tag?
A: The operating temperature range is -40℃~105℃, suitable for high-temperature sterilization (such as medical equipment) or low-temperature storage scenarios.
Q3: Does it support batch encoding?
A: Yes. UID or user data can be quickly written in batches through the reader/writer to improve deployment efficiency.
Q4: How long is the life of the tag?
A: Passive design, theoretical life of more than 10 years, read and write times ≥100,000 times, no daily maintenance requirements.
Q5: How to ensure data security?
A: Supports password protection and data encryption to prevent unauthorized tampering or cloning.
