RF-HZ40L
RS485
| Availability: | |
|---|---|
| Quantity: | |
High frequency (13.56MHz) performance readers are RFID devices optimized for industrial applications, significantly surpassing conventional HF readers in terms of recognition reliability, communication rate and environmental adaptability.
| Parameter | Specification |
| Minimum Order Quantity | one |
| Price | The price is negotiable in large quantities |
| Delivery Time | 1-2 work days |
| Stock | In Stock |
| Description | high frequency, RFID reader, Performance integrated reader, RFIDCarrier body |
| Payment Terms | T/T, Western Union |
| Supply Ability | 1000 per day |
| product model | RF-HZ40L-R4 | RF-HZ40L-TP |
| wireless protocol | ISO 15693 | |
| working frequency | 13.56MHz | |
| output power | 27.5dBm | |
| wireless speed | 26.48Kbit/s | |
| Read distance | 0~100(related to labels) | |
| communication interface | RS485 | Ethernet |
| communication protocol | MODBUS RTU | MODBUS TCP |
| Communication rate | 9600 ~ 115200bit/s | 10/100M Adaptive |
| Supply voltage | 9~30VDC | |
| Average current | <0.07A@24VDC | |
| pilot lamp | 4 LED indicators | |
| Form factor | 40x40x66mm | |
| Fixed type | 2pcs M5 Screw holes | |
| Housing material | PC+ABS | |
| Shell color | black+blue | |
| Total weight | About 110g | |
| Operating temperature | -25℃～70℃ | |
| Storage temperature | -25℃～85℃ | |
| Humidity | 5%～95%RH(No condensation) | |
| Waterproof and dustproof rating | IP67, EN 60529 | |
| Vibration resistant | 2 mm (f= 5…29.5 Hz ) , EN 60068-2-6 7 gn (f= 29.5…150 Hz) , EN 60068-2-6 | |
| Conducted immunity (CS) | 3V, over A class (including main frequency) 10V, over A class (except main frequency) | |
| Electrostatic discharge immunity ESD | Contact discharge, 8KV, over class A Air discharge, 15KV, over class A IEC 61000-4-2 | |
| Waterproof and dustproof level | IP67,EN60529 | |
| Certificate | FCC 、CE | |
| ROHS directive | 2011/65/EU,2015/863/EU | |
High frequency (13.56MHz) performance readers are RFID devices optimized for industrial applications, significantly surpassing conventional HF readers in terms of recognition reliability, communication rate and environmental adaptability.
| Parameter | Specification |
| Minimum Order Quantity | one |
| Price | The price is negotiable in large quantities |
| Delivery Time | 1-2 work days |
| Stock | In Stock |
| Description | high frequency, RFID reader, Performance integrated reader, RFIDCarrier body |
| Payment Terms | T/T, Western Union |
| Supply Ability | 1000 per day |
| product model | RF-HZ40L-R4 | RF-HZ40L-TP |
| wireless protocol | ISO 15693 | |
| working frequency | 13.56MHz | |
| output power | 27.5dBm | |
| wireless speed | 26.48Kbit/s | |
| Read distance | 0~100(related to labels) | |
| communication interface | RS485 | Ethernet |
| communication protocol | MODBUS RTU | MODBUS TCP |
| Communication rate | 9600 ~ 115200bit/s | 10/100M Adaptive |
| Supply voltage | 9~30VDC | |
| Average current | <0.07A@24VDC | |
| pilot lamp | 4 LED indicators | |
| Form factor | 40x40x66mm | |
| Fixed type | 2pcs M5 Screw holes | |
| Housing material | PC+ABS | |
| Shell color | black+blue | |
| Total weight | About 110g | |
| Operating temperature | -25℃～70℃ | |
| Storage temperature | -25℃～85℃ | |
| Humidity | 5%～95%RH(No condensation) | |
| Waterproof and dustproof rating | IP67, EN 60529 | |
| Vibration resistant | 2 mm (f= 5…29.5 Hz ) , EN 60068-2-6 7 gn (f= 29.5…150 Hz) , EN 60068-2-6 | |
| Conducted immunity (CS) | 3V, over A class (including main frequency) 10V, over A class (except main frequency) | |
| Electrostatic discharge immunity ESD | Contact discharge, 8KV, over class A Air discharge, 15KV, over class A IEC 61000-4-2 | |
| Waterproof and dustproof level | IP67,EN60529 | |
| Certificate | FCC 、CE | |
| ROHS directive | 2011/65/EU,2015/863/EU | |
1. High-speed data processing:
Tag processing speed reaches 200/second (EPC Class 1 standard)
Supports ISO/IEC 15693 and ISO/IEC 14443 A/B dual protocols
2.Precise RF control:
Adjustable field strength range 0.5-7.5A/m
Adaptive impedance matching (VSWR<1.5)
3. Industrial-grade reliability
Environmental tolerance:
Working temperature -40℃~85℃
IP67 protection grade
New Energy
Home Appliances
Automotive
Photovoltaic
Engineering machinery
Medical
Logistics
1. High-speed data processing:
Tag processing speed reaches 200/second (EPC Class 1 standard)
Supports ISO/IEC 15693 and ISO/IEC 14443 A/B dual protocols
2.Precise RF control:
Adjustable field strength range 0.5-7.5A/m
Adaptive impedance matching (VSWR<1.5)
3. Industrial-grade reliability
Environmental tolerance:
Working temperature -40℃~85℃
IP67 protection grade
New Energy
Home Appliances
Automotive
Photovoltaic
Engineering machinery
Medical
Logistics
